OPERATING LOCATION, 704TH TEST GROUP (Kirtland AFB, N.M.)

The 704th Test Group Operating Location (704TG/DE CTF) at Kirtland AFB, New Mexico provides co-located Test and Evaluation (T&E) support for Directed Energy (DE) technology currently under development at the Air Force Research Laboratory Directed Energy (AFRL/RD) Directorate.

Activated June 2006, the 704 TG/DE CTF focuses on developing test concepts, planning, methodology, procedures, and techniques for emerging DE programs. Situated at Kirtland AFB, the 704 TG/DE CTF serves as a bridge between Research and Development (R&D) and the Test and Evaluation (T&E) community. It can directly support DE technology still under development while accelerating the transition of DE technology from R&D systems to acquisition ready programs. The T&E engineers work in conjunction with AFRL/RD scientists to better understand system capabilities, providing critical requirements for long term T&E infrastructure planning.

The 704TG/DE CTF does not actively manage a test facility. The T&E engineers utilize all available resources within the test community across all military services. This allows the T&E engineers to recommend the appropriate test resources that best suit the test objectives of any DE program.

704 TG/DE CTF supports both High Power Microwaves (HPM) and High Energy Lasers (HEL) technology.

HPM Active Denial System

Advanced Tactical Laser

Self-Protect High Energy Laser Demonstrator Concept


Contacts:
Mr. John Cao, Director (505-846-0837)
Mr. Gary Anderson, T&E Engineer (505-853-8029)
Ms. Sharon Hoard, T&E Engineer (505-846-8653)


704 TG/DE CTF Directed Energy





Uses

- Embedded developmental test and evaluation personnel in AFRL's Directed Energy (DE) Directorate.

- Supports Air Force DE priorities.

- Regional DE test support through the White Sands Missile Range Test Team.


Unique Capabilities

- Joint DE test site.

- Ideal geographical location and environment.

- Extensive and specialized test infrastructure.

- Aerial cable site.

- Suburban test environment.

- Holloman's High Speed Test Track.


Developmental test and evaluation (DT&E) personnel are embedded in DoD's Center of Excellence for Directed Energy (DE) -- AFRL's Directed Energy Directorate.

- Provides in-house T&E liaison support to Major Range & Test Facility Base (MRTFB)

- Increases T&E awareness of DE technology.

- Provides test support to AFRL/RD programs.


Supports Air Force DE Priorities

- OSD's DE Test S&T Program.

- DE Technology Transition Council.

- AFMC's DE T&E Consortium.

- Test Planning and Execution




Regional DE Test Support through WSMR Test Team

- Army's WSMR and HELSTF.

- Navy's NAVSEA Port Hueneme White Sands Detachment.

- Air Force's 704th Test Group.

- Army Research Laboratory.

- Air Force Research Laboratory Directed Energy Directorate (AFRL/RD)







Salinas Peak High Altitude Test Site

- Mid-northern WSMR point 9,000 feet MSL.

- 360º azimuth field of view.

- Elevations of 3,500-4,000 ft. AGL.

- Salinas Peak is a major instrumented WSMR telemetry and communications site.

- Surface to unlimited airspace.

- Ideal to conduct passive, active or lethal test against airborne targets.

- Ideal for locating ground-based targets in the valley floor.




North Oscura Peak High Altitude Test Site

- Azimuth Field of view 360º.

- Look down angle into valley below -- for ground targets 3-35 miles.

- Restricted unlimited altitude airspace -- for airborne targets up to 120 miles.

- Elevations of 2,500-3,000 ft. AGL.

- Up to 4 test site locations.

- Plenty of power and communications.

- Existing facilities.


Why Test with WSMRs Test Team?

- Ideal geographical location and environment.

- Extensive and specialized test infrastructure.

- State-of-the-art WSMR control center.

- Joint DE Test Site.

- Aerial Cable Site.

- Holloman's High Speed Test Track.

- Suburban test environment at Playas, New Mexico.

- AFRL/RD - DoD's Center of Excellence for DE - Premier DE M&S capability - HEL and HPM infrastructure

- ARL - Electromagnetic Vulnerability Assessment Facility


Point of Contact

Directed Energy
505-853-8029 / DSN 263-8029
